GSM: 25-90g/㎡
Net paper Width: 4100mm
Jet width: 4500mm
Wire section width: 4700mm
Designed speed: 500m/min
Finished paper dryness: 92%
|
Model |
3800 |
4200 |
|
Net paper width (mm) |
3800mm |
4200mm |
|
Jet width (mm) |
4150mm |
4550mm |
|
Working speed (m/min) |
280—480m/min |
280—480m/min |
|
Diameter of holyroll (mm) |
Φ219 |
Φ219 |
|
Distribution of slurry/pulp |
Square cone pipe cloth slurry Step diffuser |
Square cone pipe cloth slurry Step diffuser |
|
Arrangement |
Left or right hand |
Left or right hand |
|
Outline size (L*W*H M) |
5600*2450*1350 |
6000*2450*1350 |
